Terminal Filter – GT Series

Design

The filter frame is made from an anodized extruded aluminium profile with two angles in each corner to get a rigid straight frame. The zinc coated hood has an attached collar and is tie glued on top of the filter. At the damper (version A) the aerosol / pressure drop checking inlet is placed in a special middle bridge and is adjustable from downstream. The fibreglass media, which is pleated in ’Minipleat shape,’ is available in three different heights (47, 56 and 70 mm) and is cast into the frame and middle bridge. This design gives a highly active filter surface and ensures the minimal pressure drop of the GT model.

Testing

Each filter is tested and packed in accordance with American Standard IEST-RP-CC-001.3 (HEPA and ULPA Filters) or in accordance with the European standard EN 1822-1, 4&5 (testing filter elements HEPA and ULPA efficiency and scan method) or customer requested testing.

Features
  • HEPA efficiencies of 95% up to 99.9995% (@ 0.3µm )
  • High quality micro fibreglass paper
  • Lowest initial pressure drop
  • Adjustable airflow by means of a damper
  • Two different damper designs
  • Anodized rigid aluminum frame
  • High quality standard due to Quality Assurance System
  • HEPA filter tested by laser particle counting system
  • Highly economical although high final pressure drop
  • For use in clean rooms up to class 1
Standards
  • EN 1822-5
  • IEST-RP-CC001.3
  • EN 779
  • ASHRAE 52.1
  • ISO 9001:2000

The GT Terminal high efficiency filter is designed and tested to extract the smallest particles out of the air. Each GT Terminal Filter contains a ‘Minipleat-Mediapack,’ available in different heights, with a new application technology of the ‘Hot Melt Spacers’ to achieve the lowest pressure drop results.

> Air Filters

Air Filters

Panel / Compact Filters

One of the most common air filtration products (high efficiency filtration) are panel filters and compact filters, applied in a variety of industries. These include filters for HVAC, cleanrooms, clean environments, healthcare facilities, laboratories, and more.

Both the panel filter and the compact filter (also known as v-shape or v-bank filter) are based on a pleated structure. It is this structure that allows greater quantities of air to pass through the filter, while reducing pressure and accumulating more dust and particles within the filter due to increase of the filtration area.

The Filt-Air panel filters and compact filters offer customers advantages:

  • Septal sizes tailored to your needs. In addition to standard filter sizes, we are able to deliver almost any size required.
  • Precise pleating technology. This unique capability ensures greater efficiency and durability over time.
  • Customized production of filter frames using a variety of materials (including. ABS, coated steel, and stainless steel), latches and handles, to meet specific standards and regulations.

Terminal Filter

Clean environments often require terminal filters that can be connected directly to the air supply or the planum.

Clean areas such as cleanrooms face a range of filter challenges, including lack of ceiling space, filter maintenance, and filter replacement. Yet with our terminal filters, you need not worry.

Over the past two decades, Filt-Air has delivered large quantities of terminal filters to a range of facilities and industries, including pharma, security, and microelectronics.

The Filt-Air terminal filters provide a range of unique advantages, including:

  • Innovative designs
  • Flexible filter housing sizes
  • Simple-to-replace filters – and simple to access

Also referred to as carbon filters, the Filt-Air gas absorption filters prevent penetration of gases into a given space. These gas absorption filters differ from partial filtration solutions (such as Fine Dust, HEPA, and ULPA), as they contain active carbon that can absorb a variety of gases. The filters may contain either granules of active carbon or a combined particle filtration media that is soaked with carbon – to ensure optimal outcomes.

The use of carbon filters is of the utmost importance for industries who deal with harmful gases, including biological institutes, chemistry manufacturers, radioactive research centers, and semiconductor manufacturers. In addition, these are widely used by defense authorities for protection against CBRN threats.

Our main advantage in the field of gas absorption filters is that we are a member of the BE Group, who began their activity in this field more than 50 years ago.

Join our long list of customers around the world who already benefit from Filt-Air products.

Power Stations / Gas Turbines

In today’s world, gas turbines are one of the most widely used power generating technologies. Gas turbines are a type of internal combustion engine, in which the burning of an air-fuel mixture produces hot gases that spin turbines, converting them into power.

As this process consumes huge quantities of air, it needs to be treated properly. Air contains a variety of elements, especially different sized particles – which could affect the efficiency of such power stations or even seriously damage them.

By employing innovative engineering capabilities, Filt-Air’s gas turbine filters enable increased air quantities combined with decreased pressure drops. This is especially important as poor inlet filtration could lead to significant erosion of surfaces (by approx. 10-micron particles), fouling of compressor blades (by 2–10-micron particles), and corrosion due to salts and acids. As such degradation processes are irreversible, they could result in serious damage to extremely costly turbines, while decreasing power generation.

Hepa Ulpa Filters
Panel / Compact Filters

Panel / Compact Filters

One of the most common air filtration products (high efficiency filtration) are panel filters and compact filters, applied in a variety of industries. These include filters for HVAC, cleanrooms, clean environments, healthcare facilities, laboratories, and more.

Both the panel filter and the compact filter (also known as v-shape or v-bank filter) are based on a pleated structure. It is this structure that allows greater quantities of air to pass through the filter, while reducing pressure and accumulating more dust and particles within the filter due to increase of the filtration area.

The Filt-Air panel filters and compact filters offer customers advantages:

  • Septal sizes tailored to your needs. In addition to standard filter sizes, we are able to deliver almost any size required.
  • Precise pleating technology. This unique capability ensures greater efficiency and durability over time.
  • Customized production of filter frames using a variety of materials (including. ABS, coated steel, and stainless steel), latches and handles, to meet specific standards and regulations.
Terminal Filters

Terminal Filter

Clean environments often require terminal filters that can be connected directly to the air supply or the planum.

Clean areas such as cleanrooms face a range of filter challenges, including lack of ceiling space, filter maintenance, and filter replacement. Yet with our terminal filters, you need not worry.

Over the past two decades, Filt-Air has delivered large quantities of terminal filters to a range of facilities and industries, including pharma, security, and microelectronics.

The Filt-Air terminal filters provide a range of unique advantages, including:

  • Innovative designs
  • Flexible filter housing sizes
  • Simple-to-replace filters – and simple to access
Fine Dust Filters
Gas Absorption Filters

Also referred to as carbon filters, the Filt-Air gas absorption filters prevent penetration of gases into a given space. These gas absorption filters differ from partial filtration solutions (such as Fine Dust, HEPA, and ULPA), as they contain active carbon that can absorb a variety of gases. The filters may contain either granules of active carbon or a combined particle filtration media that is soaked with carbon – to ensure optimal outcomes.

The use of carbon filters is of the utmost importance for industries who deal with harmful gases, including biological institutes, chemistry manufacturers, radioactive research centers, and semiconductor manufacturers. In addition, these are widely used by defense authorities for protection against CBRN threats.

Our main advantage in the field of gas absorption filters is that we are a member of the BE Group, who began their activity in this field more than 50 years ago.

Join our long list of customers around the world who already benefit from Filt-Air products.

Bag Filters
Panel Filters
Power Stations / Gas Turbines

Power Stations / Gas Turbines

In today’s world, gas turbines are one of the most widely used power generating technologies. Gas turbines are a type of internal combustion engine, in which the burning of an air-fuel mixture produces hot gases that spin turbines, converting them into power.

As this process consumes huge quantities of air, it needs to be treated properly. Air contains a variety of elements, especially different sized particles – which could affect the efficiency of such power stations or even seriously damage them.

By employing innovative engineering capabilities, Filt-Air’s gas turbine filters enable increased air quantities combined with decreased pressure drops. This is especially important as poor inlet filtration could lead to significant erosion of surfaces (by approx. 10-micron particles), fouling of compressor blades (by 2–10-micron particles), and corrosion due to salts and acids. As such degradation processes are irreversible, they could result in serious damage to extremely costly turbines, while decreasing power generation.

Coarse Filters
Bag Filters
Panel Filters

> Filtration Systems

Filtration Systems

Terminal Filter

Clean environments often require terminal filters that can be connected directly to the air supply or the planum.

Clean areas such as cleanrooms face a range of filter challenges, including lack of ceiling space, filter maintenance, and filter replacement. Yet with our terminal filters, you need not worry.

Over the past two decades, Filt-Air has delivered large quantities of terminal filters to a range of facilities and industries, including pharma, security, and microelectronics.

The Filt-Air terminal filters provide a range of unique advantages, including:

  • Innovative designs
  • Flexible filter housing sizes
  • Simple-to-replace filters – and simple to access

Fan Filter Unit

Fan Filter Units (FFU) are most frequently seen in cleanrooms, which are actively cleansed, well isolated, and have low concentrations of airborne particles.

The FFU is an essential element in cleanrooms in semiconductor manufacturing, the pharmaceutical industry, scientific research laboratories, and other facilities that require a controlled environment.

The Filt-Air FFU is a combined device within a special housing, which includes a high efficiency filter and a blower, and can also include an electronic controlling system. Multiple FFU devices can be installed on the cleanroom ceiling, in line with the specific requirements of each cleanroom and classification.

When choosing an FFU, it is important to check the following information:

  1. Power consumption and control system
  2. Noise level
  3. Unit heights (especially in low ceiling facilities)
  4. Airflow vs. pressure drop

Fan Filter Unit

Certain extra-precise measuring devices, special engineering machinery, and semiconductor manufacturing areas require the highest level of classification.

Class 1 is considered the cleanest cleanroom, with more than 500 air changes per hour and a ceiling coverage of up to 100%.

For the past two decades, Filt-Air has specialized in developing and manufacturing high-end equipment for Class 1 cleanrooms, for semiconductor industries around the globe, including military systems, measuring equipment, and many other high technology industries.

The Filt-Air FFU for Class 1 cleanrooms is a cutting edge, high technology device, capable of supplying large amounts of filtered air into the required space.

Working Stations
